Volumio2 Plugin 赤外線リモコン制御

volumio@volumio:~$ ps auxw | grep lirc
root      1592  0.0  0.1   3896  1484 ?        Ss   02:24   0:00 /usr/sbin/lircd --driver=default --device=/dev/lirc0 --uinput
root      1595  0.0  0.0   1804    68 ?        Ss   02:24   0:00 /usr/bin/irexec -d /etc/lirc/lircrc
volumio   2691  0.0  0.0   2588   528 pts/0    S+   02:33   0:00 grep lirc

tartsWith('ir-receiver'); }) === undefined) {
            self.logger.info('HAT did not load /proc/device-tree/ir_receiver!');
            exec('/usr/bin/sudo /usr/bin/dtoverlay gpio-ir gpio_pin=25', { uid: 1000, gid: 1000 },　　　　　　　　　　　　　　　　　　　　　　　　　　　　　↑

volumio@volumio:~$ ps auxw | grep lirc
volumio   8345  0.0  0.0   2588   500 pts/0    S+   03:18   0:00 grep lirc

volumio@volumio:~$ mode2 -d /dev/lirc0
space 16777215
space 4184481
pulse 10521
space 4490
pulse 736
space 492
pulse 682
space 558

volumio@volumio:~$ irrecord -n -d /dev/lirc0 test.conf

irrecord -  application for recording IR-codes for usage with lirc

Copyright (C) 1998,1999 Christoph Bartelmus(lirc@bartelmus.de)

This program will record the signals from your remote control
and create a config file for lircd.


A proper config file for lircd is maybe the most vital part of this
package, so you should invest some time to create a working config
file. Although I put a good deal of effort in this program it is often
not possible to automatically recognize all features of a remote
control. Often short-comings of the receiver hardware make it nearly
impossible. If you have problems to create a config file READ THE
DOCUMENTATION of this package, especially section "Adding new remote
controls" for how to get help.

If there already is a remote control of the same brand available at
http://www.lirc.org/remotes/ you might also want to try using such a
remote as a template. The config files already contain all
parameters of the protocol used by remotes of a certain brand and
knowing these parameters makes the job of this program much
easier. There are also template files for the most common protocols
available in the remotes/generic/ directory of the source
distribution of this package. You can use a template files by
providing the path of the file as command line parameter.

Please send the finished config files to  so that I
can make them available to others. Don't forget to put all information
that you can get about the remote control in the header of the file.

Press RETURN to continue.
（エンターを押す）

Now start pressing buttons on your remote control.

It is very important that you press many different buttons and hold them
down for approximately one second. Each button should generate at least one
dot but in no case more than ten dots of output.
Don't stop pressing buttons until two lines of dots (2x80) have been
generated.

Press RETURN now to start recording.
（エンターを押すとともリモコンのキーをランダムに押す。一押しで１ドット点が増え８０個まで続ける。）
................................................................................
Found const length: 107382
Please keep on pressing buttons like described above.
さらに同じ方法で８０個続ける。
................................................................................
Space/pulse encoded remote control found.
Signal length is 65.
Found possible header: 628 503
Found trail pulse: 603
No repeat code found.
Signals are space encoded.
Removed header.
Signal length is 32
Now enter the names for the buttons.

Please enter the name for the next button (press  to finish recording)
キーの名前を入力後エンター
KEY_PLAY

Now hold down button "KEY_PLAY".
該当キーを長押しする
Please enter the name for the next button (press  to finish recording)
KEY_UP

Now hold down button "KEY_UP".

Please enter the name for the next button (press  to finish recording)
KEY_DOWN

Now hold down button "KEY_DOWN".

Please enter the name for the next button (press  to finish recording)
エンターのみで終了
Checking for toggle bit mask.
Please press an arbitrary button repeatedly as fast as possible.
Make sure you keep pressing the SAME button and that you DON'T HOLD
the button down!.
If you can't see any dots appear, then wait a bit between button presses.

Press RETURN to continue.
エンターを押し、適当なキーを連続入力。
No toggle bit mask found.
Successfully written config file.

学習状況を確認
volumio@volumio:~$ cat test.conf

# Please make this file available to others
# by sending it to
#
# this config file was automatically generated
# using lirc-0.9.0-pre1(default) on Mon Feb 10 05:29:22 2020
#
# contributed by
#
# brand:                       test.conf
# model no. of remote control:
# devices being controlled by this remote:
#

begin remote

  name  test.conf
  bits           16
  flags SPACE_ENC|CONST_LENGTH
  eps            30
  aeps          100

  one           605  1627
  zero          605   506
  ptrail        603
  pre_data_bits   16
  pre_data       0x2FD
  gap          107382
  toggle_bit_mask 0x0

      begin codes
          KEY_PLAY                 0x48B7
          KEY_UP                   0x58A7
          KEY_DOWN                 0x7887
      end codes

end remote

Please enter the name for the next button (press  to finish recording)
KEY_PLAY

Now hold down button "KEY_PLAY".
Something went wrong. Please try again. (9 retries left)
Something went wrong. Please try again. (8 retries left)
Something went wrong. Please try again. (7 retries left)
